Description
The Jurop PN23 is a rotary vane vacuum pump that is air cooled and comes with a built-in vacuum-pressure change valve. These pumps are little workhorses and are excellent choices for slide-in pumper units and portable toilet operations. If you need to move smaller amounts of liquid in multiple locations every day, the PN23 is a powerful option. It operates at 74 CFM and has 1.5” plumbing.
NOTE: This pump is offered with Clockwise or Counter-Clockwise rotation. Select appropriate option.
Clockwise Part #: VP-JPR-23C / A010303140
Counterclockwise Part #: VP-JPR-23 / A010403140
Specifications
- RPM Range: 900-1300
- Max Continuous Vacuum: 27.6” / 92%
-
CFM at Free Air: 92
- CFM at 18”: 74
- Max Pressure: 21 PSI
- Horsepower: 4.5
- Noise at 18”: 77 dB
- Weight: 117lbs
- Oil Tank Capacity: 1.27 qt
- Recommended Oil: ISO 150
Downloads
PN Series Installation, Use and Maintenance Manual (.pdf)
